tmux

tmux

Install using tpm

If you are a tpm user, you can install the theme and keep up to date by adding the following to your .tmux.conf file:

set -g @plugin 'dracula/tmux'

Add any configuration options below this line in your tmux config.

Install with Nix

If you're using home-manager, an example config would look similar to this: Then run home-manager switch, the Activating theme section doesn't apply here.

programs.tmux = {
	enable = true;
	clock24 = true;
	plugins = with pkgs.tmuxPlugins; [
		sensible
		yank
		{
			plugin = dracula;
			extraConfig = ''
				set -g @dracula-show-battery false
				set -g @dracula-show-powerline true
				set -g @dracula-refresh-rate 10
			'';
		}
	];

	extraConfig = ''
		set -g mouse on
	'';
};

Activating theme

1. Make sure run -b '~/.tmux/plugins/tpm/tpm' is at the bottom of your .tmux.conf
2. Run tmux
3. Use the tpm install command: prefix + I (default prefix is ctrl+b)

Configuration

To enable plugins set up the @dracula-plugins option in your .tmux.conf file, separate plugin by space. The order that you define the plugins will be the order on the status bar left to right.

# available plugins: battery, cpu-usage, git, gpu-usage, ram-usage, tmux-ram-usage, network, network-bandwidth, network-ping, ssh-session, attached-clients, network-vpn, weather, time, mpc, spotify-tui, krbtgt, playerctl, kubernetes-context, synchronize-panes
set -g @dracula-plugins "cpu-usage gpu-usage ram-usage"

For each plugin is possible to customize background and foreground colors

# available colors: white, gray, dark_gray, light_purple, dark_purple, cyan, green, orange, red, pink, yellow
# set -g @dracula-[plugin-name]-colors "[background] [foreground]"
set -g @dracula-cpu-usage-colors "pink dark_gray"

Status bar options

Enable powerline symbols

set -g @dracula-show-powerline true

Switch powerline symbols

# for left
set -g @dracula-show-left-sep 

# for right symbol (can set any symbol you like as separator)
set -g @dracula-show-right-sep 

Enable window flags

set -g @dracula-show-flags true

Adjust the refresh rate for the status bar

# the default is 5, it can accept any number
set -g @dracula-refresh-rate 5

Switch the left smiley icon

# it can accept `hostname` (full hostname), `session`, `shortname` (short name), `smiley`, `window`, or any character.
set -g @dracula-show-left-icon session

Add padding to the left smiley icon

# default is 1, it can accept any number and 0 disables padding.
set -g @dracula-left-icon-padding 1

Enable high contrast pane border

set -g @dracula-border-contrast true

Hide empty plugins

set -g @dracula-show-empty-plugins false

Make the powerline background transparent

set -g @dracula-powerline-bg-transparent true

# the left separator symbol is inversed with a transparent background, you can modify it with any symbol you like
set -g @dracula-inverse-divider 

color theming

Each individual widget's foreground and background color can be overridden. Additionally, the variables used for storing color values can be overridden and extended. This allows for the use of custom themes like catppuccin or gruvbox.

For everything regarding colors, please refer to the color theming directory.

cpu-usage options

Customize label

set -g @dracula-cpu-usage-label "CPU"

Show system load average instead of CPU usage percentage (default)

set -g @dracula-cpu-display-load true

CPU usage percentage (default) - in percentage (output: %) Load average – is the average system load calculated over a given period of time of 1, 5 and 15 minutes (output: x.x x.x x.x)

battery options

Customize label

set -g @dracula-battery-label "Battery"

gpu-usage options

Note, currently only the Linux NVIDIA Proprietary drivers are supported. Nouveau and AMD Graphics Cards support are still under development.

Customize label

set -g @dracula-gpu-usage-label "GPU"

ram-usage options

Customize label

set -g @dracula-ram-usage-label "RAM"

tmux-ram-usage options

Customize label

set -g @dracula-tmux-ram-usage-label "MEM"

network-bandwidth

You can configure which network interface you want to view the bandwidth, Displaying of the interface name, The interval between each bandwidth update. The most common interfaces name are eth0 for a wired connection and wlan0 for a wireless connection.

set -g @dracula-network-bandwidth eth0
set -g @dracula-network-bandwidth-interval 0
set -g @dracula-network-bandwidth-show-interface true

network-ping options

You can configure which server (hostname, IP) you want to ping and at which rate (in seconds). Default is google.com at every 5 seconds.

set -g @dracula-ping-server "google.com"
set -g @dracula-ping-rate 5

ssh-session options

Show SSH session port

set -g @dracula-show-ssh-session-port true

time options

Disable timezone

set -g @dracula-show-timezone false

Swap date to day/month

set -g @dracula-day-month true

Enable military time

set -g @dracula-military-time true

Set custom time format e.g (2023-01-01 14:00)

set -g @dracula-time-format "%F %R"

See [this page] for other format symbols.

git options

Hide details of git changes

set -g @dracula-git-disable-status true

Set symbol to use for when branch is up to date with HEAD

# default is ✓. Avoid using non unicode characters that bash uses like $, * and !
set -g @dracula-git-show-current-symbol ✓

Set symbol to use for when branch diverges from HEAD

# default is unicode !. Avoid bash special characters
set -g @dracula-git-show-diff-symbol !

Set symbol or message to use when the current pane has no git repo

# default is unicode no message
set -g @dracula-git-no-repo-message ""

Hide untracked files from being displayed as local changes

# default is false
set -g @dracula-git-no-untracked-files true

Show remote tracking branch together with diverge/sync state

# default is false
set -g @dracula-git-show-remote-status true

hg options

Hide details of hg changes

set -g @dracula-hg-disable-status true

Set symbol to use for when branch is up to date with HEAD

#default is ✓.Avoid using non unicode characters that bash uses like $, * and !
set -g @dracula-hg-show-current-symbol ✓

Set symbol to use for when branch diverges from HEAD

#default is unicode !.Avoid bash special characters
set -g @dracula-hg-show-diff-symbol !

Set symbol or message to use when the current pane has no hg repo

#default is unicode no message
set -g @dracula-hg-no-repo-message ""

Hide untracked files from being displayed as local changes

#default is false
set -g @dracula-hg-no-untracked-files false

weather options

Switch from default fahrenheit to celsius

set -g @dracula-show-fahrenheit false

Set your location manually

set -g @dracula-fixed-location "Some City"

Hide your location

set -g @dracula-show-location false

synchronize-panes options

Customize label

set -g @dracula-synchronize-panes-label "Sync"

attached-clients options

Set the minimum number of clients to show (otherwise, show nothing)

set -g @dracula-clients-minimum 1

Set the label when there is one client, or more than one client

set -g @dracula-clients-singular client
set -g @dracula-clients-plural clients

Kubernetes options

Add prefix label before the context

set -g @dracula-kubernetes-context-label "Some Label"

Hide user from the context string

set -g @dracula-kubernetes-hide-user true

Hide ARN (show only cluster name) - Available for EKS only (only available for cluster names that are ARNs)

set -g @dracula-kubernetes-eks-hide-arn true

Extract the account as a prefix to the cluster name - Available for EKS only (only available for cluster names that are ARNs)

set -g @dracula-kubernetes-eks-extract-account true

Kerberos TGT options

Set the principal to check the TGT expiration date for (with or without the REALM)

set -g @dracula-krbtgt-principal "principal"

continuum options

Set the output mode. Options are:

• countdown: Show a T- countdown to the next save (default)
• time: Show the time since the last save
• alert: Hide output if no save has been performed recently
• interval: Show the continuum save interval

set -g @dracula-continuum-mode countdown

Show if the last save was performed less than 60 seconds ago (default threshold is 15 seconds)

set -g @dracula-continuum-time-threshold 60

Playerctl format

Set the playerctl metadata format

set -g @dracula-playerctl-format "►  {{ artist }} - {{ title }}"
